Char-Lynn Hydraulic Motor Interchange

130-1002-003 CharLynn interchange hydraulic motor

Drop in replacement for CharLynn 130-1002-003 hydraulic motor LSHT. 4.75 cubic inch displacement per revolution. 760 maximum RPM. 1,044 inch lbs. of torque. 15 maximum GPM flow rate. 4 bolt SAE flange, 1/2" NPT ports. 1" diameter shaft with...

104-1229-006 CharLynn Interchange Hydraulic Motor

Drop in replacement for CharLynn 104-1229-006 low speed, high torque hydraulic motor. 24.04 cu. in. / rev displacement. Maximum pressure 2320 PSI continuous. Torque 7786 in-lb. continuous. Maximum speed 185 RPM continuous. Flow rate 19.80...

104-1035-006 CharLynn Interchange Hydraulic Motor

Drop in replacement for CharLynn 104-1035-006 low speed, high torque hydraulic motor. 19.20 cu. in. / rev displacement. Maximum pressure 1766 PSI continuous. Torque 4956 in-lb. continuous. Maximum speed 240 RPM...

104-1034-006 CharLynn Interchange Hydraulic Motor

Drop in equivalent to CharLynn 104-1034-006 low speed, high torque hydraulic motor. 15.40 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous. Torque 3983 in-lb. continuous. Maximum speed 300 RPM continuous...

104-1033-006 Char-Lynn Interchange Hydraulic Motor

Drop in equivalent to CharLynn 104-1033-006 low speed, high torque hydraulic motor. 12.20 cu. in. / rev displacement. Maximum pressure 2061 PSI continuous. Torque 3540 in-lb. continuous. Maximum speed 375 RPM continuous...

104-1031-006 CharLynn Interchange Hydraulic Motor

Drop in replacement for CharLynn 104-1031-006 low speed, high torque hydraulic motor. 7.63 cu. in. / rev displacement. Maximum pressure 2576 PSI continuous. Torque 2724 in-lb. continuous. Maximum speed 600 RPM...

104-1028-006 CharLynn Interchange Hydraulic Motor

104-1028-006 CharLynn interchange low speed, high torque hydraulic motor. 19.20 cu. in. / rev displacement. Maximum pressure 1766 PSI continuous. Torque 4956 in-lb. continuous. Maximum speed 240 RPM continuous. Flow...

103-2088-012 CharLynn interchange hydraulic motor

Drop in replacement for CharLynn 103-2088-012 low speed, high torque hydraulic motor. 23.27 cu. in. / rev displacement. Maximum pressure 1450 PSI continuous differential.  Torque 3230 in-lb. continuous. Maximum...

105-1078-006 CharLynn Interchange Hydraulic Motor

Drop in replacement for CharLynn 105-1078-006 low speed, high torque hydraulic motor. 24.04 cu. in. / rev displacement. Maximum pressure 2320 PSI differential continuous. Torque 7786 in-lb. continuous. Maximum speed 185 RPM continuous...

105-1077-006 CharLynn Interchange Hydraulic Motor

Drop in replacement for CharLynn 105-1077-006 low speed, high torque hydraulic motor. 19.20 cu. in. / rev displacement. Maximum pressure 1766 PSI continuous. Torque 4956 in-lb. continuous. Maximum speed 240 RPM...

105-1076-006 CharLynn Interchange Hydraulic Motor

Drop in replacement for CharLynn 105-1076-006 low speed, high torque hydraulic motor. 15.40 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous. Torque 3983 in-lb. continuous. Maximum speed 300 RPM...

105-1075-006 CharLynn Interchange Hydraulic Motor

Drop in replacement for CharLynn 105-1075-006 low speed, high torque hydraulic motor. 12.20 cu. in. / rev displacement. Maximum pressure 2061 PSI continuous. Torque 3540 in-lb. continuous. Maximum speed 375 RPM...
