Char-Lynn Hydraulic Motor Interchange

CharLynn 130-1021-003 interchange hydraulic motor

CharLynn 130-1021-003 interchange hydraulic motor LSHT. 3.15 cubic inch displacement per revolution. 880 maximum RPM. 717 inch lbs. of torque. 11.85 maximum GPM flow rate. 2400 PSI maximum operating pressure. SAE 6B spline shaft. #10 SAE oring boss ports...

CharLynn 130-1020-003 hydraulic motor

Drop in replacement for CharLynn 130-1020-003 low speed, high torque hydraulic motor. 9.5 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 2170 in-lb...

CharLynn 130-1019-003 interchange hydraulic motor

Drop in replacement for CharLynn 130-1019-003 low speed, high torque hydraulic motor. 5.9 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 1425 in-lb. continuous, torque...

CharLynn 130-1018-003 interchange Hydraulic Motor

Drop in replacement for CharLynn 130-1018-003 hydraulic motor LSHT. 4.75 cubic inch displacement per revolution. 760 maximum RPM. 1,044 inch lbs. of torque. 15 maximum GPM flow rate. 4 bolt SAE flange, 1/2" NPT ports. SAE 6B spline shaft. 12...

130-1016-003 CharLynn interchange hydraulic motor

Drop in replacement for CharLynn 130-1016-003 low speed, high torque hydraulic motor. 9.5 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 2170 in-lb...

101-3690-009 CharLynn interchange hydraulic motor

Drop in replacement for CharLynn 101-3690-009 low speed, high torque hydraulic motor. 9.5 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 2170 in-lb...

130-1014-003 CharLynn interchange hydraulic motor

Drop in replacement for CharLynn 130-1014-003 hydraulic motor LSHT. 4.75 cubic inch displacement per revolution. 760 maximum RPM. 1,044 inch lbs. of torque. 15 GPM maximum flow rate. 2 bolt SAE flange, 7/8-14 ORB ports. 1"...

101-3689-009 CharLynn interchange hydraulic motor

Drop in replacement for CharLynn 101-3689-009 hydraulic motor LSHT. 4.75 cubic inch displacement per revolution. 760 maximum RPM. 1,044 inch lbs. of torque. 15 GPM maximum flow rate. 2 bolt SAE flange, 7/8-14 ORB ports. 1"...

130-1013-003 CharLynn interchange hydraulic motor

Drop in equivalent to CharLynn 130-1013-003 hydraulic motor LSHT. 3.15 cubic inch displacement per revolution. 880 maximum RPM. 717 inch lbs. of torque. 11.85 maximum GPM flow rate. 2400 PSI maximum operating pressure. 1" diameter straight keyed shaft...

130-1012-003 CharLynn interchange hydraulic motor

Drop in replacement for CharLynn 130-1012-003 low speed, high torque hydraulic motor. 9.5 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 2170 in-lb...

101-2921-009 CharLynn interchange hydraulic motor

Drop in replacement for CharLynn 101-2921-009 low speed, high torque hydraulic motor. 9.5 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 2170 in-lb...

130-1011-003 CharLynn interchange hydraulic motor

Drop in replacement for CharLynn 130-1011-003 Low speed, high torque hydraulic motor. 5.9 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 1425 in-lb. continuous, torque...
