Ross Hydraulic Motor Interchange

MG100913AAAA Ross interchange hydraulic motor

Drop in replacement for Ross MG100913AAAA low speed, high torque hydraulic motor. 9.5 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 2170 in-lb. continuous,...

MG060913AAAB Ross interchange hydraulic motor

Drop in replacement for Ross MG060913AAAB low speed, high torque hydraulic motor. 5.9 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 1425 in-lb. continuous, torque 1885...

MG060913AAAA Ross interchange hydraulic motor

Drop in equivalent to Ross MG060913AAAA low speed, high torque hydraulic motor. 5.9 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 1425 in-lb. continuous, torque 1885...

MF121313AAAB Ross interchange hydraulic motor

Drop in replacement for Ross MF121313AAAB low speed, high torque hydraulic motor. 12.16 cu. in. / rev displacement. Maximum pressure 1914 PSI continuous, maximum pressure 2576 PSI intermittent. Torque 3168 in-lb...

MF121313AAAA Ross interchange hydraulic motor

Drop in replacement for Ross MF121313AAAA low speed, high torque hydraulic motor. 12.16 cu. in. / rev displacement. Maximum pressure 1914 PSI continuous, maximum pressure 2576 PSI intermittent. Torque 3168 in-lb...

MG040913AAAB Ross interchange hydraulic motor

Drop in replacement for Ross MG040913AAAB hydraulic motor LSHT. 4.75 cubic inch displacement per revolution. 760 maximum RPM. 1,044 inch lbs. of torque. 15 maximum GPM flow rate. 4 bolt SAE flange, 7/8"-14 ORB ports. 1" diameter shaft...

MG040913AAAA Ross interchange hydraulic motor

Drop in replacement for Ross MG040913AAAA hydraulic motor LSHT. 4.75 cubic inch displacement per revolution. 760 maximum RPM. 1,044 inch lbs. of torque. 15 maximum GPM flow rate. 4 bolt SAE flange, 7/8"-14 ORB ports. 1" diameter shaft...

MG090913AAAB Ross interchange hydraulic motor

Drop in replacement for Ross MG030913AAAB hydraulic motor LSHT. 3.15 cubic inch displacement per revolution. 880 maximum RPM. 717 inch lbs. of torque. 11.85 maximum GPM flow rate. 2400 PSI maximum operating pressure. 1" diameter straight keyed shaft. #10...

MG090913AAAA Ross interchange hydraulic motor

Drop in replacement for Ross MG030913AAAA hydraulic motor LSHT. 3.15 cubic inch displacement per revolution. 880 maximum RPM. 717 inch lbs. of torque. 11.85 maximum GPM flow rate. 2400 PSI maximum operating pressure. 1" diameter straight keyed shaft. #10...

MG201313AAAA Ross interchange hydraulic motor

Drop in replacement for Ross MG201313AAAA low speed, high torque hydraulic motor. 23.6 cu. in. / rev displacement. Maximum pressure 1450 PSI continuous, maximum pressure 2060 PSI intermittent. Torque 3850 in-lb...

MG181313AAAB Ross interchange hydraulic motor

Drop in replacement for Ross MG181313AAAB low speed, high torque hydraulic motor. 19.0 cu. in. / rev displacement. Maximum pressure 1625 PSI continuous, maximum pressure 2060 PSI intermittent. Torque 3575 in-lb. continuous,...

MG181313AAAA Ross interchange hydraulic motor

Drop in replacement for Ross MG181313AAAA low speed, high torque hydraulic motor. 19.0 cu. in. / rev displacement. Maximum pressure 1625 PSI continuous, maximum pressure 2060 PSI intermittent. Torque 3575 in-lb. continuous,...
